XS2 Owners ManualYamaha XS1 - TX650 Parts Manual and Model ID
This manual is in Adobe Acrobat format (pdf). I realize this is not the most efficient format for graphics, but I think it is the best choice for this particular use due to it's cross platform capabilities and great features. You must have Adobe Acrobat to read these files. The software is free and I put a link here at the bottom. This parts manual references the 1970 XS1, 1971 XS1B, 1972 XS2 and 1973 TX650 models, however much of it will be applicable to other Yamaha 650 SOHC twins.
NOTE: Files contained on this page are from obsolete sources and may contain errors. Use at your own risk.
XS650 Motorcycle Model ID
(data extracted from Yamaha microfiche 1962-1986 Motorcycle Model ID, US and Canada, and other sources)
Data is Model, Serial number refers to starting engine/frame number, model year and stock color(s)
| Model | Serial Number | Year | Color(s) |
|---|---|---|---|
| XS1 | S650-000101 | 1970 | Candy Green |
| XS1B | S650-007101 | 1971 | Candy Orange |
| XS2 | S650-100101 | 1972 | Brilliant Red |
| TX650 | S650-200101 | 1973 | Metallic Flake Blue |
| TX650A | 447-000101 | 1974 | Cinnamon Brown |
| XS650B | 447-100101 | 1975 | Star Black |
| XS650C | 447-200101 | 1976 | French Blue |
| XS650D | 447-700101 | 1977 | Maxi Maroon, Bountiful Blue |
| XS650E | 2F0-000101 | 1978 | Star Black*, Spruce Metallic Green |
| XS650SE | 2F0-100101 | 1978 | Vintage Burgundy, New Midnight Black |
| XS650F | 2F0-150101 | 1979 | Cobalt Blue |
| XS650SF | 2F0-250101 | 1979 | Carmine Red, Black Gold |
| XS650-2F | 4F0-250101 | 1979 | New Yamaha Black |
| XS650G | 3G0-000101 | 1980 | Black Gold |
| XS650SG | 2F0-200101 | 1980 | Cardinal Red, New Yamaha Black |
| XS650H | 4N9-000101 | 1981 | Indigo Blue, New Ruby Red |
| XS650SH | 4M4-000101 | 1981 | New Yamaha Black, Frost Silver |
| XS650SJ | 5V4-000101 | 1982 | New Yamaha Black |
| XS650SK | 5V4-100101 | 1983 | New Yamaha Black, New Ruby Red |
* - Microfiche references STAR BLUE which is not correct
